FabriCAM Software P56 Advanced Home Part Shape (Part 25) Step by Step Video Tutorial

fabricam advanced home part shape
Once again we will be covering yet another home looking Flat Part shape, but slightly more advanced though.
The advanced P56 Flat Part could also be viewed a bit like an old barn type shape as well.
This video is part of a Mini-Series.
Previous video covered P55 Advanced Tri Rectangles.
Video Transcript
Hi guys. In today's video, we're gonna be looking at part number 56 from our advanced flat parts. But before that, let's have a quick intro first. So today's video can be found on softwaretraining.co.za. We make sure we need to watch problem solving videos, and we also have daily updates. Otherwise, we had to head into the programme here. Yeah, this is gonna be our last shape for the advanced parts. So we have finally come to an end of, unfortunately, moved a few shapes from this, uh, little canvas just to make more space. I don't know if I would have fit everything in. Maybe I should have left it just to play a bit more dangerous and, uh, experiment a bit, but, yeah, today's shape, it's gonna be a pretty much We've already covered a shape, which kind of looks like a house. I think it was in our intermediate section. Now we're gonna be covering a more advanced shaped house. In my opinion, it kind of looks like a factory a little bit like a factory. So, uh, that's why no means the name of the shape that's just the way I remember it. So then let's go here to flat part. What I wanna do is go to p 56. As you can see here, this kind of reminds you of us. Old school factories are not factories, bonds or something like that. So you could have a door here, so if they had, that shape would have been ideal, but yeah, so it's not the most advanced shape, but it is our last advance shape. So now we can set width and height like usual. And then we've got you over a C, which is the side walls. And then we've also got an X for top walls for the roof. I mean, sorry. Why? And then we've got an X, which is the width of the top shape. So now if you have to look at it in a sense of shapes, you will notice we've got a rectangle at the bottom rectangle on top, and then we basically have joined or filled in the middle. So let's add this. I'm gonna see if we can kind of squeeze in this space. Um, I think this was about what was it 2 50 around there. So if we go about 500 could even try 600. So So let's go with our B. I'm gonna go 600 just to see if we're fortunate and we fit it in, Then a, I would say 200 maybe. What is that? But 3. 50. So let's go about. I'm gonna go bud 30 25 and then next up, we've got our sea, which is the side wall, so I can make this one a bit larger. So I'm gonna make this maybe about 200 and then we've got our X. So if our top with is what is at 3 25 let's make this quite a bit smaller. Gonna make this about 80 and then we've got the top height. Which this one I'm thinking maybe making about 50. Yes, maybe a bit small. So let's make it 100. Let's preview this. What we've got Yeah, I've got some chapel looking place, so I'm gonna try this. We add one manual added and see if we can fit it in here. Uh, where my measurements were out quite a bit. So basically my worth is fine. It's just my height So let's quickly go. And we set out who overall height or we can do is just set the top or just the walls. So let's go read that part. Then we go at it again. Now, the tricky part is remembering everything. So I'm gonna make this one just be safe. We went 600 I'm gonna go 500. Then be oh, it. This one has to be 500 this one to make it about was it 3. 25? Then we've got our sea Which the sidewalls It's gonna make this a bit more random. So 100 x, the width of it with the width of the top shape. Let's go 80 again and then I'll make this one about 25 this time. See the shape of Mandela quantity. And then we had this. So if we better Okay, this summit at least fits in Don't have to do it a third time, but yeah, there we go. That is our last part. Part 56. Thank you guys, for joining me on this mini series of, uh, black parts, uh, ended up not being quite a miniseries. It was quite a large series we had. Yeah. What is it? Three different categories who had to end up covering, But yeah, otherwise. Now you should know these shapes. Quite, uh, intimately. Otherwise, we're headgear softwaretraining.co.za C Uh, you guys will notice We've got a variety of different Softwares we do cover. And you can also isolate your search on the top. Right? If you do not, however, find the training videos you're looking forward to something like, Yeah, request the training video, fill in the many form, and then we'll do our best to try and make that for you. But otherwise thanks, guys watching and cheers.
