TruCUT RDWorks Dislocation of the Circle Type (Part 16) LGP Design Videos Mini-Series

rdworks circle type dislocation

Having a look at the Dislocation option for the LGP Design Circle Type within the program.

Now even though we have already covered this option in regards to the Line Type, the effect we get for the Circle Type is not quite the same.

This video is part of a Mini-Series.
Next video covers LGP Design – Circle Round Preview.
Previous video covered LGP Design – Reversed Values.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

mhm other guys in today's video. We're gonna be looking at your circle dislocation option now before the L G P design feature. But before that, let's have a quick intro first. So today's video can be found on softwaretraining.co.za c o dot z We make sure and easy to watch problem solving videos. And we also have the updates otherwise back in the programme here now. Yeah, we've already looked at the dislocation for the normal, um, grid or lines I think it was. And today we're gonna be looking at the so call now, the ship Here are the short, simple video. So I'm gonna create a circle shape here, make sure our type is set to circle on top here, and then we go to this option dislocation. Now, in my opinion, with a circle type, is this pretty? I don't wanna say useless, but it's, you know, change happens, but it's really hard to spot it because this is already I'm spiralling out. So in essence, these things should be aligned to a point. But as you can see over here, the changes because we've got extra ones in between now when we enable this and we click apply. It kind of tries to, uh, uh, offset them. But as you can see, over a year, they still align and at some point creates a vehicle. So, uh, when it comes to the dislocation for the circle, maybe you find a use for it. But in my opinion, I don't see the, uh, a big change when you enable or disable only slight change. But yeah, I'm not to waste too much time on this feature. Um, if we head here to softwaretraining.co.za c o dot Today you guys will notice we've got a variety of different Softwares you do cover. And also you can isolate your search on the top, right? If you do not, however, find a training video you're looking forward to simply go your request a training video filling in uniform and will make that video for you. But otherwise thanks, guys, for watching and cheers
