# FabriCAM Software P48 Advanced Rectangle Circle (Part 22) Step by Step Video Tutorial

fabricam p48 advanced rectangle circle

Once again we will be combining the classic Rectangle and Circle, but in this case we will get more advanced.

This current setup of shapes we have covered a number of times already, but what makes this shape more advanced is the layout option.

This video is part of a Mini-Series.
Next video covers P51 Rounded Rectangle Combo.
Previous video covered P45 Rounded Triangle Rectangle.

### Training Video with Voice-Over ( Sounds ON ), Please Subscribe

#### Video Transcript

Hi guys. In today's video, we're gonna be looking at part number 48 from our advanced parts. But before that, let's have a quick intro first, so today's video can be found on softwaretraining.co.za z. We make sure and easy to watch problem solving videos, and we also have daily updates. Otherwise, we head back into the programme here and now Part 48. In many ways, it's gonna be quite a simple shape or a simple part even though it is advanced. Um, we've covered it a few times where we we kind of have a circle cut out in some form of rectangle. In many ways, this is gonna be the most, uh, basic form you're gonna be getting. But it comes with the exception of the circle not being just get centred. And you can actually a judge that centres all this centre cut out location, but yeah, so if we're heading to it, we're gonna go here too. Um, flat parts and they will navigate apart 48. So when I opened this, you guys can see what I mean with them, even though it's got many values to set is very simple. We've got a rectangle with a circle cut out. And like I said, what makes this shape advance is the fact that you can set the location of the circle within this cut out where normally it will be centred, and you'll just be adjusting the actual diameter of this circle cut out. So, yeah, let's do this. I'm gonna go go about 2 50 then by 200 just so that we don't have a rectangle so we don't have a square. We're gonna have a little rectangle here and I'm gonna try and make This may be a bunch 80 and then we're gonna just the actual X and y. Now I think for the X, I'm gonna be a bit larger. So let's go about, let's see, 2. 10, I think, And then for the why I wanna have it a bit more centred. So that one we can go 100 its previous. This what looks like Okay, it's a bit close to me on the edge, so I'm just gonna bring it back a bit. Let's make about 1 90 and then here we go. Kind of like that. So I'm gonna say manual 21 add to add this to our plane where I want to see it on the preview. And then there we go. I'm gonna fit under there. So with this one up a bit, So just to recap on part 48. So like I mentioned that, what makes this one advances the fact that your circle cut out you can place anywhere within your rectangle, so that is something to keep in mind. But otherwise we're here to softwaretraining.co.za. Guys will notice. You've got a variety of different Softwares we do cover, and you can also isolate your search on top. All right, if you do not, however, find the training videos you're looking forward to simply go. Yeah, request training, video filling the mini form. And then we'll do our best to try and make that for you. But otherwise thanks, guys, for watching and cheers
