FabriCAM Software Flat Part P33 Intermediate Shape (Part 18) Step by Step Video Tutorial

fabricam intermediate shape part p33

When it comes to the Flat Part P33 it is in many ways very similar to the previous part that we just covered.

This part has a few exceptions that makes it a bit different from the previous part which makes it a bit more advanced.

This video is part of a Mini-Series.
Next video covers P43 Rectangle with Rounded Edges.
Previous video covered P32 Rectangle Angled Cut Out.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

How are you guys? In today's video? We're gonna be looking at part 33 from our intermediate flat parts. But before that, let's have a quick intro first. So today's video can be found on softwaretraining.co.za We make sure to watch problem solving videos, and we also have daily updates otherwise back into the programme here. So now, as you guys can see, our list of intermediate part is growing quite a bit. Now in today's video, we're gonna be looking at part 33 now this in many ways almost a reverse of part 32. But with the exception that yeah, we've got extra values we can set. So from a three part shape, we're gonna go to a four part shape now, four options shape. So let's go to flat parts. Go to P 33. And as you guys can see from the preview here, we now have four different values. We can say we've got a B, C and A. D. So now you could almost reverse the part 32 with us. But yeah, that is not quite the purpose of this shape. You can also, if you for instance, had to say, Let's say see, larger than be or the larger than a. Then you can get some funky looking shapes, which I would recommend You'd rather keep it within the, um, within this preview kind of layout. Now, let's just quickly go through it. So we've got a So we were at the height. I'm gonna set this to about 1. 57 b two, maybe 300 then the C and the D we can set separately. So this sea I've got 300 So I'm gonna go about half 1 50 then the d. Obviously, ideally, we don't want it larger than a So let's make this Maybe, uh, it's good. I leave. The name is quickly preview this. Now we can see what type of shape we've got here now, like I mentioned, if we had to up the values that say from C and D larger than A and B, then let's really do that. So see, go larger than be, which is 300. So let's go about 3 50 and then let's go d larger than A, which is 100 5200. Preview this and as you can see we start getting some interesting shapes. A rectangle and triangle mix on the top. Now, Yeah, In my opinion, you won't ever really need to use that. You'll start to just make a rectangle and triangle. So I'm just gonna set these two down. Just got you 50 to 50 values, and we'll leave it at that. Let's go, manual 21. Add this. And then we've got this shape we can add to our canvas or I'll cut away. So, like I said in this one, in my opinion, some of these other shapes you can see the values to extremes, and you get two different shapes that you could use. Like like I mentioned with the shape B 12. But when it comes to the p 33 I would recommend just stay within the same values or the default values and then use that shape as is. But yeah, that is it on p 33. If we head here to softwaretraining.co.za You guys will notice We've got a variety of different Softwares we do cover. And you can also isolate your search on the top, right? If you do not, however, find the training videos you're looking forward to simply go your request, the training video, filling the mini form. And then we'll do our best to try and make that for you. But otherwise thanks guys for watching and churches.
