FabriCAM Software CAD Information Identifier Panel (Part 3) Step by Step Video Tutorial

fabricam cad identifier panel

When it comes to the CAD Information Identifier Panel, we will be using this to identify key information.

This video is part of a Mini-Series that covers Navigation for the CAD feature.

Next video covers Location Identifier.
Previous video covered Information Identifier.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

Hey, guys, In today's video, we're gonna be looking at your information identified for the cat feature, and this will be four favorite game software. But before that, let's have a quick intro first. So today's video can be found a softwaretraining.co.za. And we make sure an easy to watch problem solving videos. And we also have daily updates if we are heading to the programme here. So now just a reminder. This is a miniseries on the navigation of the cad. So I'm gonna open up a cat here. We've already looked at our navigation widget are three D widget and now we're gonna be looking at the information identified here. Now, this is a very handy feature. Um, if you're not sure what what, in a sense of the workflow and so forth that can sometimes be helpful? Not always, but it is definitely worth while using this. So in the bottom left here at the moment, we cannot see anything. But, uh, if I had to use the operator many times, I will show you the operator what it's doing and give you some prompts as well. So let's say like in the previous miniseries we did on the creating all the basics where we created a shape. Let's say if I click on the rectangle here, you will see now here at the bottom, it tells us a rectangle. So we've got an idea. Okay, cool. That's busy happening. Let's just move the zoom two, another monitor. And then, um yeah, we've got a tool tip there that it is busy happening. So now let's add some dimensions. I'm gonna 500 by 100. Uh, okay. And then now we can see is prompting us something else. It says click on single linear matrix or circular positioning, then click on the screen. So it's kind of give us a prompt here of what to do next, which is nice. So we know now. Okay, we must click on one of these. Yeah, Harvard, with your mouth. You can see the names of them. So if you're not sure what it's talking about, you know, over on these icons, then let's click on the single positioning and then it says, Then click on the screen. Click on that and it gives us that problem, Say okay and then adds it to our things. So as you can see, it's cleared it again. So it's nothing there. And yeah, so this is very handy little feature. If you're getting stuck, consider looking there. Maybe it's prompting you something that, uh um, you are missing or so forth. So, like I said, it's gonna be a very handy thing once again. Just to recap will show you relevant information about where you're going and what could be done. But yeah, otherwise, before we head on to the next video, if we go to softwaretraining.co.za z, you guys will notice we've got a variety of different Softwares we do cover, and you can also isolate your search on the top, right? If you do not, however, find the training videos you're looking forward. Just simply go here, request the training video, filling the form, and then we'll do our best to try and make that for you. But otherwise thanks guys for watching and just
