TruCUT RDWorks Software Export the LGP Design (Part 28) LGP Design Videos Mini-Series

rdworks export lgp design

This is great when you are making a LGP Design but you prefer doing the final cutting in program.

The LGP Design features are very similar to the programs processing options, but with a few small differences.

This video is part of a Mini-Series.
Next video covers LGP Design – LGP Preview.
Previous video covered LGP – GoScale, CutScale, Delete All.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

Hi there, guys. In today's video and truth that already works. We're gonna be looking at how to export your L G P design, um, within the programme. But before that, let's have a quick intro first. So today's video can be found on softwaretraining.co.za c o dot We make sure and easy to watch problem solving videos. We also have daily updates otherwise back on the programme. Yeah, Now, just a quick reminder. This isn't really serious on the l g P design feature, and I will also leave relevant links in the description so you guys can follow along. Let me just remove this quick. So now if we head into the l g p actual future, let's say you've set up a custom shape just quickly. Make one year, then I'm scale this. Maybe around 200 say apply. Let's say we've set up everything the way we like it. I've got a spacing. We've got our outlines and all of that by 21 in your actual programme so you can make further changes or so forth all incorporated into the design. And then what you can do is we go here at the bottom to export L G P design if I click that to automatically thrown into our designer and obviously relevant to the size we created. But we can go on these little arms and skated up all down if you want to. Something that's worth noting, however, is that once you've exported it, it exported as a lot of individual shapes. So as you can see all of these shapes and I had to just click here, select whatever is underneath my mouth. So if you want to move the whole thing, you're gonna have to drag a selection box right over it, and then you can move it. But I would highly recommend once you've imported it, you can always select this. And then we hit the little group button on the top menu. I mean, top to bottom to click group. And then now our entire thing is grouped. Now, if you want to, you can always custom we set here on the colours. Uh, what do the individual colours do so you can set up if you want the red? So let's say just engrave and the blue to cut right through, and we can do that setting up afterwards. So this is a great way if you want to have your classic trick that already works, um, settings. You on the right if you wanna adjust those manually yourself and not through the actual l G P design feature, but, yeah, that covers the show. So that's just about everything on the export l g B L g p design my apologies. I always get that wrong. And then, yeah, if we had year to softwaretraining.co.za got CEOs today, guys will notice we've got a variety of different Softwares we do cover. And you can also isolate your search on the top, right? If you do not, however, find the training videos you're looking forward to simply go your request, the training video, fill in the uniform. Then we'll do our best to make that for you. But otherwise, thanks, guys, for watching and cheers
