Having aTruCUT RDWorks the LGP Light Position Types (Part 6) LGP Design Videos Mini-Series

rdworks lgp light positions

When it comes to the Light Positions, this will determine where the LGP design will be lid from.

There are a few different categories to choose from, all with their own options and setups.

This video is part of a Mini-Series.
Next video covers LGP Design – Base Line Row and Col.
Previous video covered LGP Design – Preview Navigation.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

Hi, guys. In today's video, we're gonna be looking at the different light positions you get for your L G P design feature. And this will be for that already works. But before that, let's have a quick intro first. Mm mm. Mhm. So today's video can be found on softwaretraining.co.za c o dot z. We make sure that easy to watch problem solving videos, and we also have any updates otherwise, back in the programme here. Now, just a quick reminder that these ministers on the L, g P design and I will also leave relevant links in description so you guys can follow along. Now, when it comes to the light positions, we get three different types and each one of those has their own positions. So if we have to head to the feature on a crowbar, I'm just gonna add a basic rectangle and then change its type of grid. Okay, it already is. And then maybe zoom out of it so we can nicely see Now we've got these red lines and the blue lights. Now the blue lines is the direction of the light. So if you want to know where the light comes from Just look at your blue lines and then you will note on the first tap parameter tab. We've got one side to side and also so we started here on one side. We've got light purse of position and light cross position. So then, like position At the moment we can see bottom, right? Br And as we see this is the bottom, right? So now if we change this, let's say we go to the top left, so it should be here now In order to see the change, just head to another tab and back again and it will update the change for you. As you can see There Now we've got blue is now on the top left. Obviously you can run through all the other ones. They will say I'll show you the relevant updates then next up, we've got to side. So this is too light sources. So the moment we've got top left on top of right. So when we change tabs here, it should show us Blue Cross like this. Go there we can see the blue. But now you might notice We've got an extra red line and now If we go here to cross position, we'll see bottom Middle. So now this is the bottom middle. This is the cross point in the middle. Obviously, you have things like, let's say, um top right and bottom. Right. Uh, this should do this side. So if I click Tab, you can see now our light source is coming from the top, right and bottom. Right. And this is a cross position. So it will be the middle left, as we can see over there. And then the last option we have here is the fourth side. We click this, but only have one option available from the drop down, which is, as you can see, all directions. Top left, top right, bottom right, bottom left and cross point position is centre. So if we had to change this, you will see we've got a nice blue rectangle around with a cross in the middle. So yeah, that is then how you set your light positions. Just a quick recap. We've got one side to side and four sided. And where the red is, or at least the red lines on your canvas. That is the cross points and the blue lines is the origin or that area your light is coming from. And, uh, yeah. So otherwise, that is it on the light positions. If we had to head here to softwaretraining.co.za c o dot z A. You guys will notice we've got a variety of different Softwares will recover. And you can also isolate your search on the top, Right? If you do not, however, find the training videos you're looking forward. Just simply go here, request the training video filling in uniform. There's no for which software. And then we'll do our best to try and make that for you. But otherwise thanks guys, for watching, and she is.
