TruCUT RDWorks Aligning Objects to the Page (Part 4) the Arrange Bar Video Mini-Series

rdworks aligning shapes objects

When it comes to aligning shapes and objects, we get two different types to choose from in TruCUT RDWorks.

These two types are usually referred as local and global alignments, Local being the location within a selection of shapes, and Global referencing to the design area itself.

This video is part of a Mini-Series.
Next video covers Snap to Edge.
Previous video covered Scaling.

Training Video with Voice-Over ( Sounds ON ), Please Subscribe

Video Transcript

All right, guys, in today's video is true. That already works. We're gonna be looking at how to align objects and shapes to the page using a few features located on your range box. But before that, let's have a quick intro first. Mm. So today's video can be found on softwaretraining.co.za c o dot Today We make sure that easy to watch problem solving videos, and we also have daily updates. Otherwise, back in the programme here. Now, just a quick reminder. This is a miniseries on the range bar, and I will leave relevant links in the description so you guys can actually follow along now if you do not see your range. But if for any reason, just go simply to your view and then make sure your range. But it's gonna write Mark and you click on it, then, Uh, yeah, when it comes to these features, this is, um, to arrange objects or shapes to your page so we can simply do as you click your shape and then you can see on a range. But we've got the top left corner. We click that will take it to the top left top right bottom, right, bottom left and then we have centre. Now if we had to throw another shaping here and then you select both of them now if we do the same thing, you will notice. It treats the shape selected as a shape. So it's got bored borders going right around it, so it will not throw them all together like something like this when you do a top right corner, just something to keep in your mind. But yeah, so it's rather simple. Like I said, it's just you can align it to your page. Unfortunately, not have won the centre bottom centre top centre right on the left. So for that you will have to manually, um, move to that. Otherwise that is it. On aligning shapes and objects to your page with features located on a range bar. We had to adhere to softwaretraining.co.za hat you guys will notice. We've got a variety of different software to recover, and also you can isolate your search on the top, right? If you do not, however, find the videos you're looking for, just go here, request a training video filling the mini form. Then we will make that video for you. But otherwise thanks guys for watching and cheers
